Keypad and LEDs
ARB Keypad
The ARB Module keypad has 5 keys; the top three are associated with alarm screen operation, the bottom two with the Bluetooth interface and buzzer operation:
|
Up and Down keys - Cycle through Alarm messages for each transmitter - see Alarm Screen. |
|
Enter - See Alarm Screen. |
||
Bluetooth - See MM7000 Mobile Data Upload. |
||
Mute - Silences alarm buzzer - see Relay / Buzzer and MS100 Card Operation. |
LEDs
The ARB Module has 3 LEDs:
Red LED
This LED flashes to indicate that alarm screen(s) are available to view on the OLED display; see Alarm Screen.
Amber LED
This LED indicates the network status. At power up, the amber LED will flash quickly while network settings are acquired; before going to slow flash while connecting to the Synergy Server and, finally, solidly on, once connected to the server.
During normal use, a fast flash indicates loss of network connection and a slow flash indicates a loss of connection to the Synergy Server.
Green LED
The green power LED will illuminate during normal operation; it will go off during a power fail condition.
